DATA SHEET
For which swimming pools ?

	Hydroxinator® 10	Hydroxinator® 18	Hydroxinator® 22	Hydroxinator® 35
Volume of water treated (temperate climate, filtration 8 hours/day)	40 m3	70 m3	100 m3	150 m3
Nominal chlorine production	10 g/ora	18 g/ora	25 g/ora	35 g/ora
Nominal output amperage	2,2	3,6	4,5	7,2



User interface: 4-line, backlit LCD screen
Languages: 7 (FR-EN-DE-ES-IT-NL-AF)
Operating modes: Normal, Boost (100%), Low (shutter mode 10%)
Clock / Timer: 24 hr clock / 2 timers
Polarity inversion: Yes: 2.5 or 5 hour (factory setting = 5 hour)
Recommended mineral rate - minimum: 5 g/L - 4.5 g/L min

Safety features:
"Minerals" indicator: Production reduced to protect the electrode at low mineral levels.
"No flow" indicator: Production is interrupted as long as conditions are not ideal.
Mechanical flow rate sensor: YES
Cell position: Horizontal
Compatible pipes: DN50 mm, DN63mm, 1½ '' (48 mm), 2'' (61 mm)

TECHNICAL SPECIFICATIONS

Cell life span*	10,000 hours (titanium plates, MagnaPool™- specific SC6 ruthenium treatment)
Power rating	195 W
Minimum flow rate (needed to purge air from the cell)	5 m³/hr
Maximum flow rate	18 m³/hr (above this, by-pass required)
Maximum permitted pressure in the cell	2,75 bar (KPa)
Maximum water temperature	40 °C
Minimum water temperature	5 °C
Length of cable from control unit to cell	1,8 m
Protection factor	IP23
Cell dimensions (W x H x D)	32,0x13,5x11,0 cm
Dimensions of the cabinet (W x H x D)	31,0x33,0x11,0 cm
50 Hz power supply	220-240 VAC
*Under good operating conditions



GENERAL
Unconditional guarantee: 3 years
Composition MagnaPool® system
Hydroxinator® + MagnaPool® Minerals + Crystal Clear filtration media



EFFECTIVE AND STABLE DISINFECTION
The Hydroxinator® automatically purifies the water, generating magnesium hydroxide with clarifying properties. When the pool water is treated manually, the chlorine concentration varies considerably between each addition. With MagnaPool®, the natural purifying properties of magnesium generated by the Hydroxinator act gently and continuously, without the "saw-tooth" effect. Result: continuously disinfected water that is healthy and always perfectly balanced for comfortable bathing.



WATER THAT IS GENTLE ON THE SKIN AND EYES
40% less chloramine
Zodiac® research has demonstrated that the MagnaPool® system generates 40% less chloramine than water treatment using salt chlorination.
Chloramines are developed 4 times more slowly in a MagnaPool® pool than in water treated manually with chlorine or by salt chlorination.
With MagnaPool®, you are choosing an aquatic environment with water which is gentle on the skin, hair and eyes.



EASY TO INSTALL AND USE
The Hydroxinator® is easy to install and use, with a simple and intuitive interface. It requires no special maintenance other than an occasional visual check.
